10kV to 200V/240V Pole Mounted Single Phase Transformer with 35kV Input and 440V Output
1. Product Description
This multi-voltage grade Pole Mounted Single Phase Transformer is a versatile outdoor distribution transformer designed for flexible medium-voltage to low-voltage power conversion, supporting dual input options of 10kV and 35kV, as well as multi-range output of 200V, 240V and 440V. Different from conventional single-specification power transformers, this outdoor single-phase pole transformer integrates multiple voltage conversion modes in one unit, which can adapt to diverse overhead grid voltage standards in different regions, solving the matching problem between medium-voltage overhead lines and terminal low-voltage electrical loads.
Manufactured in full compliance with ANSI, IEEE and IEC international power equipment standards, the oil-immersed insulated structure ensures stable operation in open-air environments. The device adopts high-purity copper winding and high-permeability silicon steel core, effectively reducing no-load loss and load fluctuation during voltage conversion. As a universal overhead distribution transformer, it supports 50/60Hz conventional power frequency operation, features compact pole-mounted structure and fully sealed anti-leakage design, and is a practical multi-spec voltage conversion equipment widely used in civil, rural and light industrial power supply systems.
The biggest advantage of this 10kV/35kV multi-input single-phase transformer lies in its flexible voltage matching capability. It can switch between 10kV and 35kV high-voltage input according to on-site grid conditions, and freely output standard 200V/240V civilian voltage and 440V light industrial voltage, which greatly reduces equipment replacement costs for power construction and grid renovation projects.
2. Core Uses
The core function of this 10kV to 200V/240V and 35kV to 440V pole mounted transformer is to realize safe, accurate and stable step-down conversion of medium-voltage overhead power. It converts 10kV or 35kV high-voltage grid power into usable low voltage that meets civilian and light industrial power standards, providing reliable voltage conversion and power distribution for terminal electrical equipment.
In daily grid operation, this multi-voltage single-phase distribution transformer can effectively stabilize grid voltage, suppress line surge interference, and avoid electrical equipment damage caused by excessive or unstable input voltage. It undertakes decentralized power distribution, voltage regulation and electrical isolation tasks for overhead power grids, improves the safety factor of outdoor power supply, and reduces line power loss in medium and short-distance power transmission.
For scattered power supply areas and multi-scenario power consumption environments, the dual-input and multi-output design eliminates the need to configure different transformers for different voltage demands. It can simultaneously meet household 200V/240V daily power consumption and small equipment 440V industrial power demand, realizing multi-purpose power conversion and greatly improving the flexibility and economy of regional power distribution.
3. Application Scenarios
3.1 Rural Overhead Grid Power Supply
It is highly suitable for rural power grid renovation and rural scattered household power supply projects. Many rural overhead power grids have mixed 10kV and 35kV line layouts, and household electrical equipment mainly uses 200V and 240V voltage. This pole mounted single phase transformer can adapt to different high-voltage line inputs in rural areas, stably output standard household voltage, and meet the power demand of rural lighting, household appliances, water pumps and daily civilian equipment.
3.2 Suburban Light Industrial Power Distribution
For suburban small processing workshops, rural handicraft factories, small agricultural machinery equipment and light industrial facilities that require 440V power supply, this 35kV input 440V output transformer provides stable low-voltage industrial power support. It can perfectly match the power demand of small motors, processing equipment and auxiliary electrical systems, solving the problem of inconvenient power taking for decentralized light industrial sites.
3.3 Remote Area Off-Grid Power Supply
In remote mountainous areas, pastoral areas and island areas with imperfect power grid construction, overhead power lines often have unstable voltage grades and mixed specifications. This multi-voltage conversion transformer can flexibly adapt to 10kV and 35kV incoming lines, and freely switch 200V, 240V and 440V output according to local power consumption needs, effectively solving the difficulty of power matching in remote off-grid and weak grid areas.
3.4 Temporary Outdoor Engineering Power Supply
It is widely used for temporary power supply of outdoor construction sites, road engineering, communication base station auxiliary power supply and field operation projects. The pole-mounted installation is fast and convenient, and the multi-voltage output can meet the power needs of construction lighting, small construction machinery and field monitoring equipment, providing safe and stable temporary power guarantee for various outdoor engineering operations.
3.5 Residential and Community Auxiliary Power Supply
It can be used for power distribution of suburban communities, villa areas and scattered residential blocks. The 200V/240V stable output fully covers residential daily power consumption, while the reserved 440V output interface can support community public equipment such as elevators, water supply equipment and landscape lighting, realizing one machine for multiple purposes in community power supply.
4. Product Features
4.1 Multi-Voltage Flexible Matching, Wide Compatibility
This innovative single-phase pole transformer supports dual 10kV/35kV high voltage input and triple 200V/240V/440V low voltage output, covering most common medium and low voltage grades in civil and light industrial power systems. It is compatible with various specifications of overhead power lines and terminal electrical equipment, avoiding the trouble of customized equipment selection for different voltage demands, and greatly improving the universality of outdoor power distribution equipment.
4.2 Low Loss and High Efficiency, Energy-Saving Operation
Adopting high-quality low-loss silicon steel sheet core and precision wound copper coil, the equipment features low no-load current, small magnetic leakage and low operating loss. Whether in 10kV or 35kV input mode, it can maintain efficient energy conversion, effectively reduce long-term operation power consumption, and meet the energy-saving and consumption reduction standards of modern power grids. The stable load resistance ensures no obvious efficiency drop under half-load and full-load operation.
4.3 Outdoor Weather Resistance and Long Service Life
As a professional outdoor pole-mounted distribution device, the whole machine adopts fully sealed oil-immersed structure and multi-layer anti-corrosion spraying process. It has excellent waterproof, rainproof, ultraviolet resistance and high and low temperature resistance, and can operate stably in harsh outdoor environments such as high temperature, severe cold, humidity and dust. The sealed oil tank effectively prevents insulating oil deterioration and moisture ingress, ensuring long-term stable operation and extending the overall service life of the transformer.
4.4 Simple Pole Mounted Installation and Low Engineering Cost
The product is designed with an integrated fixed bracket for standard electric pole installation, with a compact overall structure and moderate weight. It does not require complex foundation pouring and indoor equipment room construction, and can be quickly installed and put into use on site. The simple installation process shortens the construction cycle of power grid projects, and the multi-functional design reduces the purchase quantity of single-spec transformers, effectively saving engineering procurement and construction costs.
4.5 Safe and Stable Operation with Complete Protection
Equipped with overvoltage protection, overload protection, short-circuit protection and pressure safety protection devices, the transformer can automatically cut off the circuit and protect the equipment when encountering grid surge, overload operation and line short-circuit faults. The high-strength insulation structure ensures excellent electrical insulation performance, effectively avoiding electric leakage and equipment failure, and adapting to long-term unattended outdoor overhead operation.
4.6 Low Maintenance and Strong Practicability
The fully sealed structural design avoids frequent oil replenishment and internal cleaning work. The product has low failure rate and stable operating performance in daily use, and only needs regular appearance inspection and oil quality detection. It is very suitable for rural power grids, remote areas and temporary engineering scenarios with inconvenient later maintenance, with extremely high on-site practicability and economy.
