1. Product Description

The 15kVA 35.5kV to 120V/240V three single phase oil immersed transformer is a customized combined single-phase distribution transformer set designed for 35.5kV medium-voltage power grid systems. This three-unit single-phase oil-filled transformer bank integrates three independent 15kVA single-phase oil immersed transformers, which work in tandem to support three-phase grid access while outputting standard 120V and 240V split-phase low voltage for end-user power consumption. Tailored for North American standard power distribution requirements, this 35.5kV step-down oil immersed transformer efficiently converts high 35.5kV medium voltage into dual 120/240V single-phase power, fully matching residential, light commercial and remote field electrical equipment operating standards.

Manufactured in strict accordance with ANSI/IEEE C57.12 and DOE energy efficiency standards, each single-phase unit of this three single phase 15kVA 35.5kV 120/240V oil immersed transformer adopts high-quality low-loss grain-oriented silicon steel core and high-purity oxygen-free copper winding structure. Equipped with PCB-free mineral insulating oil immersion cooling and fully sealed corrugated tank design, the whole transformer set features stable insulation performance, low operating loss and excellent weather resistance. Different from conventional integral three-phase transformers, the three-single-phase combined structure allows independent operation of each unit, convenient separate maintenance and flexible load allocation, making it a reliable and cost-effective power transformation solution for decentralized medium-voltage power distribution projects.

2.  Technical Parameters

3. Core Purpose

The core purpose of the 15kVA 35.5kV to 120V/240V three single phase oil immersed transformer is to provide segmented, safe and low-consumption voltage step-down conversion for 35.5kV medium-voltage power distribution systems. This three-unit single-phase transformer bank solves the problem of mismatched voltage levels between high-voltage overhead transmission lines and low-voltage single-phase electrical loads, stably converting 35.5kV high grid voltage into standard 120V and 240V dual output voltage that meets North American residential and light commercial power supply specifications.

Different from traditional integrated three-phase transformers, this three single phase oil immersed power transformer supports independent operation of each single-phase unit. It can balance three-phase grid load while supplying split-phase single-phase power for decentralized users, effectively reducing three-phase load imbalance and grid harmonic interference. It stabilizes terminal output voltage, avoids voltage surge and drop caused by load changes, and ensures safe and compliant power consumption for scattered low-power loads. As a key supporting device for 35.5kV rural and suburban power grids, it optimizes power distribution efficiency and improves the overall stability of regional medium-voltage power systems.

4. Application Scenarios

Thanks to its independent single-phase unit design, low power consumption, flexible installation and strong outdoor adaptability, the 15kVA 35.5kV/120V/240V three single phase oil immersed transformer is widely applied in decentralized low-load power supply scenarios that require three-phase grid access and single-phase power output. It is the preferred equipment for 35.5kV medium-voltage power grid construction and renovation in suburban and rural areas:

• Rural Decentralized Residential Power Supply: Perfect for scattered rural households and remote suburban residential communities. The three single-phase combined structure evenly distributes three-phase grid load, while each unit provides stable 120V/240V household power supply for daily lighting, household appliances and living electricity, solving unbalanced load problems in rural power grids.

• Suburban Light Commercial Power Distribution: Suitable for suburban small retail stores, street service outlets, small office rooms and community supporting facilities. It supplies reliable single-phase power for low-power commercial equipment and office devices, meeting low-load and long-duration commercial power consumption demands.

• Remote Field Monitoring & Communication Power Supply: Widely used in field monitoring stations, forestry observation equipment, highway roadside facilities and remote communication base stations. With excellent outdoor weather resistance and unattended operation capability, it provides continuous stable power for field low-power equipment.

• 35.5kV Rural Power Grid Upgrading & Renovation: Ideal for old grid reconstruction and capacity expansion of North American standard 35.5kV medium-voltage rural power grids. It replaces outdated high-loss transformers, balances three-phase load distribution and improves overall power supply quality and energy-saving efficiency.

• Decentralized New Energy Grid Connection: Matched with small scattered rooftop photovoltaic power generation systems in rural and suburban areas. The three single-phase transformer set completes stable voltage conversion and grid-connected power distribution for new energy equipment, effectively optimizing new energy grid access stability.

• Outdoor Temporary Engineering Power Supply: Adaptable for temporary power guarantee of rural infrastructure maintenance, small outdoor construction and public facility renovation projects. Its independent unit design allows flexible single or multi-unit operation according to actual load demands.

5. Product Features

This 15kVA 35.5kV to 120V/240V three single phase oil immersed transformer adopts upgraded energy-saving design and ANSI standard manufacturing technology. The combined three-single-phase structure brings unique operational advantages compared with conventional integral transformers, with outstanding performance in energy saving, operational flexibility, safety stability and environmental adaptability:

• Independent Unit Operation & Flexible Load Matching: Composed of three independent 15kVA single-phase oil immersed transformers, the whole set can realize balanced three-phase grid access. Each unit operates independently without mutual interference, supporting single-unit independent operation or multi-unit combined operation according to actual load conditions. It effectively solves three-phase load imbalance in decentralized power supply scenarios and improves grid power utilization rate.

• Ultra-low Energy Loss & High Cost Performance: Every single-phase unit adopts high-permeability low-loss silicon steel core and high-purity copper winding, minimizing no-load iron loss and load copper loss. The overall power consumption is far lower than industry standard values. For long-term low-load operation in rural and suburban areas, it significantly reduces daily grid operation energy consumption and user operating costs.

• Dual 120V/240V Stable Output: Optimized single-phase winding structure ensures balanced and accurate dual 120V and 240V voltage output. The built-in multi-grade off-circuit voltage regulation device can adapt to regional 35.5kV grid voltage deviation, effectively suppress voltage fluctuation and harmonic interference, ensuring terminal electrical equipment operates under rated stable voltage.

• Fully Sealed & All-weather Outdoor Adaptability: Each transformer unit adopts fully sealed oil tank structure, isolating internal insulating oil and core windings from external moisture, dust and corrosive air. The whole machine uses high weather-resistant anti-corrosion electrostatic spraying coating, resisting ultraviolet aging, rain erosion, frost and snow damage, supporting long-term unattended outdoor operation in complex environments.

• High Insulation Strength & Operational Safety: Strict 35.5kV medium-voltage insulation design with 150kV BIL lightning impulse resistance provides excellent over-voltage, lightning protection and short-circuit resistance. Each independent unit has independent insulation protection, which can avoid overall equipment failure caused by single-unit fault, greatly improving power supply reliability.

• Low Noise & Easy Maintenance: Optimized core vibration reduction and mute winding process effectively reduce operating noise, meeting residential area environmental protection standards. The independent unit design supports targeted single-unit inspection and maintenance without affecting the normal operation of other units, lowering daily maintenance difficulty and later operation cost.

6. FAQ (Frequently Asked Questions)

Q1: What are the advantages of three single phase oil immersed transformers over integral three-phase transformers?

The 15kVA 35.5kV 120/240V three single phase oil immersed transformer adopts a split combined structure with three independent single-phase units. Compared with traditional integral three-phase transformers, its biggest advantage is flexible load adaptation and high operational stability. It can effectively balance three-phase grid load for decentralized single-phase power loads and avoid common three-phase imbalance problems in rural power grids. When a single unit fails or needs maintenance, the other two units can still work normally without overall power outage. In addition, it can output standard 120V/240V dual single-phase voltage that integral three-phase transformers cannot directly provide, which is more in line with North American residential power supply habits.

Q2: Can this 35.5kV three single phase transformer operate stably in extreme outdoor environments?

Absolutely. This three single phase oil immersed transformer set is fully optimized for outdoor harsh working conditions. Each single-phase unit adopts a fully sealed oil tank structure with PCB-free environmentally friendly insulating oil, which completely prevents internal insulation damp, oil deterioration and dust pollution. The high-strength anti-corrosion shell can resist long-term ultraviolet radiation, heavy rain erosion, low-temperature freezing and high-temperature aging. With a wide operating temperature range of -40℃ to +45℃, it can run continuously and stably in extreme cold winter and hot summer seasons. It has passed ANSI outdoor environmental adaptability tests and is fully applicable to long-term unattended outdoor pole-mounted and pad-mounted installation scenarios.

Q3: What daily maintenance work is required for three single phase oil immersed transformer banks?

This 15kVA three single phase oil immersed transformer has low daily maintenance threshold and stable operational performance. Daily inspection mainly includes checking the oil tank sealing status of each independent unit to confirm no oil leakage, and observing the insulating oil level and clarity to ensure the oil is free of turbidity and deterioration. Regularly clean dust and sundries on the surface of the radiator to guarantee unobstructed heat dissipation and prevent overheating faults. Periodically test the insulation resistance and operating temperature of each single-phase winding, and check the tightness of high and low voltage wiring terminals. The independent unit design allows targeted maintenance of faulty units without overall shutdown. With standardized routine maintenance, the overall service life of the transformer set can reach more than 20 years.
